Northstar FBB GC1.
Folding boxboard of virgin fibre. Triple-coated front, single-coated back. Three bulk grades to optimise stiffness against weight. Engineered for consistency, built to run clean.
Construction
Multi-ply
Coating
3 / 1
Fibre
Virgin
Standard
GC1
Select a grade.
01 — Standard
FBB Fine
Excellent flatness, high brightness, built for high-speed printing
Grammage range
200300400 gsm
Triple coated
Virgin fibre
FSC
Download tech data sheet
PDF
§ Interactive
Grammage & caliper.
Pick a grammage from the selected grade to see the corresponding thickness, stiffness, and typical applications. Caliper is to scale.
Grammage
270g/m²
Thickness
270 µm
Stiffness MD
5.0 mN·m
Stiffness CD
2.5 mN·m
Typical use
Pharma
§ Technical Data
Full comparison.
Fine
Fine Bulk
Super Bulk
| Property | FBB Fine | FBB Fine Bulk | FBB Super Bulk | Method |
|---|---|---|---|---|
| Physical — base | ||||
| Grammageg/m² · ±3% | 210–400 | 225–360 | 205–345 | ISO 536 |
| Thicknessµm · ±3% | 270–555 | 340–555 | 310–545 | ISO 534 |
| Moisture% · ±1.5 | 7.5 | 7.5 | 7.0 | ISO 287 |
| Surface | ||||
| PPS Roughnessµm · top, 75 / max | ≤ 1.5 | ≤ 1.5 | ≤ 1.6 | ISO 8791-4 |
| Gloss (top)% · min | ≥ 45 | ≥ 45 | ≥ 40 | ISO 8254 |
| Brightness (top)D65/10 · min | 90 ± 3 | 90 ± 3 | 89 ± 3 | ISO 2470-2 |
| Brightness (back)D65/10 · min | 88 ± 3 | 88 ± 3 | 87 ± 3 | ISO 2470-2 |
| Printability | ||||
| IGT Picking — topm/s · min | ≥ 1.3 | ≥ 1.3 | ≥ 1.3 | ISO 3783 |
| Ply BondJ/m² · min | ≥ 130 | ≥ 130 | ≥ 130 | TAPPI 569 |
| Cobb Top (60s)g/m² · max | ≤ 60 | ≤ 60 | ≤ 60 | ISO 535 |
§ Construction
Multi-ply,
Multi-ply,
precision coated.
Every Northstar FBB sheet is a multi-ply construction: triple-coated LBKP + NBKP on top, a high-bulk BCTMP core in the middle, LBKP + NBKP on the bottom, and a single coating on the reverse.
The three front coating passes build a smooth, uniform print surface. The core provides stiffness-at-weight. The back coat keeps the reverse clean and printable.
